Line graphs are a great way to organize and present your data. If you use Microsoft Excel to compile, present, and analyze data, then you’re in luck – Excel has a handy feature that allows you to convert information into a line graph!

In this simple step-by-step guide, we’ll teach you how to make a line graph in Microsoft Excel, so you can present your data in style.

So read on, and you can learn how to make great line graphs in a matter of seconds!


How To Make A Line Graph In Excel

How to make a line graph in Excel



Create A New Spreadsheet

To begin, you need to create a new spreadsheet. Open Microsoft Excel by clicking on the icon, and select the ‘Blank Workbook’ option. This will open a fresh spreadsheet ready for you to use.



Enter Your Data

Now you want to start filling in your data. When making a line graph, you want to separate each section by column.

Line graphs have two axes, so you’ll need two columns of data (although you can use more if you want additional lines on your graph).
The left-most column defaults to the X-axis, so it is more convenient to put the data for time in the left column.

For instance, if you were measuring something monthly you should list each month descending in the left column.

Adding a title header at the top of each column is handy as Excel will automatically add these titles to the data on your line graph.



Select The Data You Want In Your Line Graph

Next, select all the data you want to be represented in the line graph.

To do this, simply click and drag your mouse from the top-left cell to the bottom-right cell of your columns.

This will highlight all your data. Alternatively, you can just click in the top-left cell, then click on the bottom-right cell while holding the shift key to do the same.



Create The Line Graph

Now it’s time to turn your data into a line graph! With your spreadsheet highlighted, click on the ‘Insert’ tab located at the top of your screen.

This will open up a banner below with several different sections; one of these sections will be labeled ‘Charts’.

In the ‘Chart’ section, you’ll see several different icons representing styles of graph.

The Line Graph icon looks like two crisscrossing lines, like what you would see on a line graph.

Click on this to open up a drop-down menu.
In this menu, you will find several different styles of line graphs.

It’s up to you to choose which style you want, and there are plenty of options to choose from.

If you hover over a style in the menu, it will show you a preview on your spreadsheet of what the line graph will look like.

When you’ve chosen a style, click on it to create the line graph in your spreadsheet.




Customize Your Line Graph

With your line graph created, you’re free to customize it however you want.

You can easily move and resize it by dragging from the center or by the dots around the edge; you can also move and resize elements within the graph itself in the same way! If you want to change the graph title or rename the axis, double-click on the text to open the textbox.

Finally, if you want to change the graph style, you can do this at any point in the top banner!


And there you are! Now that you know how to make line graphs in Excel, you can start presenting your data in style. Just use the steps in this guide, and you can make great line graphs in no time!
