AMD RX 7600 XT vs Nvidia RTX 4070 Super: Do they compare?

We look at the battle between the AMD RX 7600 XT vs Nvidia RTX 4070 Super

Two graphics cards in comparison against a neutral background with an "AMD RX 7600 XT vs Nvidia RTX 4070 Super" symbol between them.

You can trust PC GuideOur team of experts use a combination of independent consumer research, in-depth testing where appropriate – which will be flagged as such, and market analysis when recommending products, software and services. Find out how we test here.

Last Updated on

If you’re on a bit of a budget, then you’ll want to weigh up the RX 7600 XT vs RTX 4070 Super. Both cards serve to provide playable framerates in 1080p and 1440p as top mainstream options, but they go about things in wildly different ways. For more, we recommend checking out our RTX 4070 Super review, which goes through the card in even more detail.

Want to go deeper? We also have the best monitors for the RX 7600 XT and a dedicated feature on the RTX 4070 Super and RTX 4070 Ti all just a click away. Let’s continue here for now.

✓ Overview

Do the AMD RX 7600 XT and Nvidia RTX 4070 Super compare?

Yes. Priced similarly, the 7600 XT and 4070 Super target 1440p with comparable performance. Nvidia offers better ray tracing/DLSS 3, while AMD might win on raw value.

AMD RX 7600 XT vs. Nvidia RTX 4070 Super: Specs

The AMD RX 7600 XT and Nvidia’s RTX 4070 Super are the latest generation of GPUs, featuring the RDNA 3 and Ada Lovelace architectures, respectively. In terms of components, the RTX 4070 Super appears to have a significant advantage. Its strongest components are the 56 Compute Units/SM Count and higher shader processing capability.

Additionally, the higher number of AI Accelerators/ROPs in the RTX 4070 Super (80 compared to 64) suggests better capabilities in handling artificial intelligence workloads, better graphics and overall rendering efficiency.

SpecsAMD Radeon RX 7600 XTNvidia GeForce RTX 4070 Super
GPU ArchitectureRDNA 3.0Ada Lovelace
Transistors13,300 million35,800 million
Compute Units/SM Count3256
AI Accelerators/ROPs6480
VRAM16 GB GDDR612 GB GDDR6X
Base Clock Speeds1720 MHz1980 MHz
Boost Clock Speeds2755 MHz2475 MHz
Memory Clock2250 MHz 18 Gbps effective1313 MHz 21 Gbps effective
Memory Interface128-bit192-bit
L1 Cache128 KB per Array128 KB (per SM)
L2 Cache2 MB48 MB
L3 Cache32 MBN/A
TBP/TDP190W220W
Memory Bandwidth288 GB/s504.2 GB/s
MSRP$329$599
Specs table for the AMD RX 7600 XT and Nvidia RTX 4070 Super

While the RX 7600 XT has a higher boost clocks at 2755 MHz compared to the RTX 4070 Super’s 2475 MHz, the base clock of the RTX 4070 Super is notably higher at 1980 MHz compared to the RX 7600 XT’s 1720 MHz. These higher clock speeds provide the 4070 Super with a fighting chance.

To continue, the RTX 4070 Super has a larger memory interface at 192-bit compared to the RX 7600 XT’s 128-bit. The RTX 4070 Super also features faster memory with a 21 Gbps effective clock speed. This results in a significantly higher memory bandwidth of 504.2 GB/s compared to the RX 7600 XT’s 288 GB/s.

This difference in memory bandwidth can impact the GPUs’ ability to handle high-resolution textures and perform memory-intensive tasks — giving the RTX 4070 Super an advantage in memory-related performance.

AMD RX 7600 XT vs. Nvidia RTX 4070 Super: Performance

From the technical specs and benchmark results released, it is clear that there is a mismatch in real-world performance between the two GPUs. However, let’s delve into the range of performance differences. The main disparity between the two being the RTX 4070 Super’s 56 Compute Units/SM Count and 80 AI Accelerators/ROPs.

Enabling the model to handle realistic graphics with greater efficiency, making it a more powerful option for demanding applications such as gaming and content creation. Additionally, the higher memory bandwidth of the RTX 4070 Super ensures smoother handling of full-HD textures, average FPS and an overall performance boost in memory-intensive scenarios.

Ray tracing and AI capabilities are key differentiators here too, with NVIDIA traditionally holding an edge in these areas. AMD’s RDNA 3 architecture could introduce advancements that bring them closer to or even surpass NVIDIA’s offerings. A positive for AMD is the announcement of FSR 3, its answer to Nvidia’s DLSS 3.

FSR 3 is available in over 20 console and PC games, while its core features are operating at a driver level across thousands of video games, unlike Nvidia’s DLSS 3. This helps the Radeon RX 7600 XT improve its performance and rectify some disadvantages discussed so far.

While the RX 7600 XT may deliver satisfactory performance, the RTX 4070 Super’s superior specifications position it as a more robust choice for users seeking a better performance in top-tier graphics and select games.

SpecificationAMD RX 7600 XTNvidia RTX 4070 Super
ArchitectureRDNA 3Ada Lovelace
CUDA Cores (Nvidia) / Stream Processors (AMD)40967680
Memory8 GB GDDR612 GB GDDR6X
Ray Tracing PerformanceDecentExcellent
DLSS SupportFSR (AMD’s DLSS competitor)DLSS 3 (Nvidia’s latest upscaling tech)

AMD RX 7600 XT vs. Nvidia RTX 4070 Super: Price comparison

When it comes to price and value, the RX 7600 XT emerges as an appealing option for budget-conscious consumers. Priced at $329, it offers a competitive balance between affordability and performance. The RTX 4070 Super, with a higher price tag of $599, targets users who prioritize cutting-edge specifications and are willing to invest in top-tier performance.

The decision between the two GPUs depends on individual budget considerations and performance requirements. While the RTX 4070 Super provides superior capabilities, the RX 7600 XT offers a compelling value proposition for users seeking a capable GPU without breaking the bank. Assessing the performance-to-price ratio is crucial in determining which GPU aligns better with the user’s preferences and financial considerations.

What is the power of the Radeon RX 7600 XT?

The AMD Radeon RX 7600 XT has a board power of 190W. This power is less than that of the RTX 4070 Super, which boasts 220W overall. Despite having less power, the RX 7600 XT does still hold some impressive specs. Be sure to reference the specs table above when considering purchasing the model.

Is the RTX 4070 Super, better than the 4070?

In short, yes. Nvidia tends to increase the level of performance above the cards they replace. This means that the RTX 4070 Super provides a decent upgrade in specs and performance over the RTX 4070. This increase can range from around 15% in DLSS and 10 to 20% in gaming and graphics.

Final verdict

From our thorough evaluation, the choice between the RX 7600 XT and RTX 4070 Super boils down to individual priorities and use cases. The RTX 4070 Super stands out as a performance powerhouse with advanced features and capabilities. Overall, offering a more immersive gaming experience. However, the higher price point may be a limiting factor for those on a budget.

On the other hand, the RX 7600 XT presents a compelling option for users looking for a balance between performance and affordability. With a more modest price tag, it provides satisfactory performance for a wide range of applications.
